Zenith 913 Brick Laying Machine

description1
Zipper closure 1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout
Product Features

ZENITH 913 Brick Laying Machine, Made in Germany, is the ideal concrete brick making machine for economical mass production of high quality concrete blocks & cement bricks.

Available in semi-and fully automatic execution. Outstanding performance in open area or buildings. Safe handling and well proven design principles guarantee efficient operation of ZENITH 913 brick machine, even still in decades. Different molds are easily interchangeable. The machine produces concrete bricks directly onto the ground, in lines – cycle by cycle. Running wheels of brick machine are outfitted with Vulkollan coating for protection of concrete floor. Equipped with hydraulic shunting wheel for turning of brick machine at end of production lines. More than seven thousand machines of this type of laying brick machines are in operation – worldwide.

ZENITH offers for all travellers comprehensive equipment for concrete brick handling. Cubers with special brick clamps are available. Transport of fresh concrete from mixing plant to brick making machine is preferably made with a forklift equipped with a hopper or with a special concrete loader. Ask ZENITH for the options available.

Technical Parameters

Features

Hopper Volume

1000 L

Loader Feeding Height max.

2005 L

Max. Production Width

1240 mm

Max. Production Depth

1130 mm

Min. Production Height

175 mm

Max. Production Height

330 mm

Weight

With Mould & vibration motor

5 T

Machine dimensions

Total Length

2850 mm

Total Height max.

3000 mm

Total Width

2337 mm

Vibration system

Max.4 Mould vibrators

48 KN

Max.2 Tamper Head Vibrators

20 KN

Electrics

Power Consumption with Max. nos. of Vibrators

16 KW

Technology Advantage
